Optical switchboard ORM 16 SDF SIS

intended for welding, and storing connectoring splitter 1: 8, 1:16. Box is ideal for FTTx applications ; Capacity of 16 optical connectors ; Connector holder SC simplex, duplex SC ; Piling version (ORM 16 SDF SIS) ; Extra 2 optional adapter...More information

Producer

OEM

Code

00030696

Warranty

24 Month

Availability

Availability in stores

Order

Your price exc. VAT

264.98 EUR exc. VAT

VAT

21%

Your price inc. VAT

320.62 EUR inc. VAT

Ask for a better price

Description

Designed for welding, connecting and storage of splitter 1: 8, 1:16. Box is suitable for FTTX applications

capacity of 16 optical connectors

SC Simplex connectors, SC Duplex

pillar version (orm 16 sdf sis)

extra 2 optional adapter positions for connecting an input optical cable with a splitter or for measurement through one protruding fiber from the splitter.

1-2 Optical cartridges KM1 for storing welds

2 × space for lining incoming and outgoing fibers

parameters:

name	value
Bushes:	2 × PG 13.5; 1 × PG 29 patchcord-24 holes
degree of coverage:	IP 54 according to ČSN EN 60529
degree of self-extinguishing:	v0 according to UL 94
impact protection degree:	k 10 according to ČSN EN 50102
sunlight (UV):	ČSN EN 60068-2-5
Temperature Test Test:	-40 ° C/+70 ° C according to ČSN EN 60068-2-145
Color:	Light gray RAL 7035
Material-switchboard:	PVC, PC/ABS
Material-Bushings:	pa6, tpe-s
Material-metal parts:	aluminum
Dimensions (mm):	1747 × 290 × 209
Weight (kg):	11
