Optical cable, J/A-(ZN)H, FTTx DROP, 4vl., 9/125, G657A, 3mm, LSOH

Name: Optical cable, J/A-(ZN)H, FTTx DROP, 4vl., 9/125, G657A, 3mm, LSOH
Brand: OEM
SKU: 36700
Price: 0.45 EUR
Availability: OutOfStock

Universal optical cable for indoor and outdoor use, with the possibility of hinge, LSOH cloak, 4 fibers, singlemode, (SM), 9/125, 7A01, drop, 3mm, KDP, OFS Allwave, black colorMore information

Producer

OEM

Code

00033073

Warranty

24 Month

Availability

Availability in stores

Order

Your price exc. VAT

0.37 EUR exc. VAT

VAT

21%

Your price inc. VAT

0.45 EUR inc. VAT

Ask for a better price

Description

The 7A01 cable is one of the best-selling cables of the present. It is produced in a single-od design with 2-24 fibers and LSOH with a cloak.

bend radius 1 cm in loop, fiber G.657A

cable diameter 3 mm

Possibility to use in both internal and external environments

option to be up to 130 m

G.657-Defines optical fibers that produce lower attenuation levels caused by bending. The minimum bend radius was reduced to 15-5 mm (depending on the version). The G.657A fiber is compatible with G.652 fiber, G.657.B do not provide 100# i6per# compatibility with other fibers, although they have unique mechanical properties suitable for the most demanding devices.

parameters:

name	value
number of threads:	4
cable diameter (mm):	3
Weight:	10 kg/km
Short-term tensile load (n):	500/TD>
Long-term tensile load (n):	-
Installation temperature (° C):	5 to 40
Operating temperature (° C):	-20 to 60
storage temperature (° C):	-20 to 60
