Self-tapping keystone Solarix 10G Cat 6a STP RJ45, black, SXKJ-10G-STP-BK-SA

Self-tapping Keystones Solarix is characterized by a very simple installation that does not need to use a cutting tool. These keystones without any problems meet the parameters specified in international standards of structured cabling ANSI/TIA 568, ISO/IEC 11801 and EN 50173 for category 6a and class EA line, including all the latest amendments. Keystones are fitted with an 180 ° self-tapping terminal block, which is marked with a color scheme according to the type of connection, either according to the standard T568A or T568b. In this terminal block it is possible to cut cables with wires of AWG 26-22. The standard color of the non-closed self-tapping Keystones Solarix is black, in the shield version the body of the module is fonden to the silver metal part. Thanks to their compact dimensions, these self-tapping keystones are compatible with modular drawers of most manufacturers (eg ABB, Schneider, Legrand, Moeller, Hager, Horizon, etc.).

Fulfilling the performance parameters of Keyston Solarix SXKJ-10G-STP-BK-SA was confirmed by the independent Delta test laboratory. Keystones received a certificate at the Connecting Hardware level from this test authority. Tests were held including compatibility with POE and POE+ (according to IEC 60512-99-001: 2012).

parameters:

name	value
Category:	Cat6a
Supported protocols:	10GBASET
Shielding:	Yes
min. Porter life:	1000 wiring/disconnection
contact coverage:	50 µ gold and 100 µ nickel
terminal:	quick-cutting
wire size:	AWG 26-22
Material of non-metallic parts:	FR plastic by UL94-0
Color:	black
storage temperature (° C):	-40 to 70
Operating temperature (° C):	-10 to 60
Max. Operating humidity:	93#i6per#
