ADEL System DFX6048A, industrial power supply, 48V/1.25A, 60W

Name: ADEL System DFX6048A, industrial power supply, 48V/1.25A, 60W
Brand: ADEL System
SKU: 69406
Price: 43.13 EUR
Availability: InStock

The Adel System DFX6048A is an AC/DC source with an input voltage of 90-305 V and a DC output of 48 V/1.25 A, ie with the possibility of connecting a device with a power input of up to 60 W. Thanks to a miniature size, it is a great solution to the switchboard.More information

Producer

ADEL System

Part No.

DFX6048A

Code

00074464

Warranty

36 Month

Availability

Availability in stores

Order

Your price exc. VAT

35.65 EUR exc. VAT

VAT

21%

Your price inc. VAT

43.13 EUR inc. VAT

Ask for a better price

Description

A series of miniature DIN industrial DC power sources from traditional Italian manufacturer Adel System brings the best technologies to the category of affordable sources. The model DFX6048A is AC/DC source with an input voltage of 90-305 V and DC
The output voltage can be controlled in the range of 46.5 to 50 V, the source can withstand up to 30# i6per# overload of the output without disconnecting the load . The output is protected against short-circuit, overload and overvoltage. Wide working temperature range (- 25 ° C to 70 ° C ), compact size including DIN rail holder and above standard 3 years warranty are a prerequisite for reliable operation at all times.

key features:

Input: 90-305 VAC
Output: 48 VDC /1,25 and /60 W
Efficiency: More than 83#i6per#
Overload option up to 30 #i6per #
output is protected against short-circuit, overload and overvoltage
compact size + assembly on DIN
3 years warranty

Parameters

Physical parameters
DC Output Voltage (V)	48
DIN rail mounting	Yes
Input Voltage (V)	230
Management	No
Ochrana proti zkratu	Ano
Output Current (A)	1.25
Output Power (W)	60
Over temperature Protection	Ano
Properties	Průmyslový
Depth (mm)	55
Design	DIN rail
Efficiency (%)	83
Height (mm)	90
Operating Temperature	-25° až +70 °C
Weight (kg)	0.2
Width (mm)	54
