ADEL System DFX1524A, industrial power supply, 24V/0.6A, 15W

A series of miniature DIN industrial DC power sources from traditional Italian manufacturer Adel System brings the best technologies to the category of affordable sources. The model DFX1524A is AC/DC source with an input voltage of 90-305 V wide range and a DC
The output voltage can be controlled in the range of 22.5 to 28 V, the source can withstand up to 50# i6per# overload of the output without disconnecting the load . The output is protected against short-circuit, overload and overvoltage. Wide working temperature range (- 25 ° C to 70 ° C ), compact size including DIN rail holder and above standard 3 years warranty are a prerequisite for reliable operation at all times.

key features:

• Input: 90-305 VAC
• Output: 24 VDC /0.65 and 15 W
• Efficiency: More than 81#i6per#
• Overload option up to 30 #i6per #
• output is protected against short-circuit, overload and overvoltage
• compact size + assembly on DIN
• 3 years warranty
