IMCO POWER TIC241.H 24_4806 inverter, 24V DC/48V DC, 300W

Name: IMCO POWER TIC241.H 24_4806 inverter, 24V DC/48V DC, 300W
Brand: IMCO POWER
SKU: 50146
Price: 664.27 EUR
Availability: OutOfStock

Industrial DC/DC converter 18-35V/48V (6A) with galvanic separation, with remote signal Soft Start and prevedenia on DIN rail.More information

Producer

IMCO POWER

Part No.

EV004264

Code

00070524

Warranty

36 Month

Availability

Availability in stores

Order

Your price exc. VAT

548.99 EUR exc. VAT

VAT

21%

Your price inc. VAT

664.27 EUR inc. VAT

Ask for a better price

Description

DC converter TIC241.H 24_4806 converts the input voltage 18-35 V to the output voltage 48 V with galvanic separation. The converter is equipped with a local LED indication on the front panel, the long-distance signaling is via a free relay contact.

The converter is designed to mount on din bar . Connecting input, output and signaling is via the removable connector at the bottom of the converter with a cross-section of the wires up to 2.5 mm

2 .

Parameters

Ethernet parameters
DC Output Voltage (V)	48
DIN rail mounting	Yes
Input Voltage (V)	24
Local signalling	LED
Ochrana proti přepětí	Ne
Output Current (A)	6
Output Power (W)	300
Properties	Tepelná ochrana, Ochrana proti zkratu, Ochrana proti podpětí
Rack mounting	Ne
Remote signalling	Kontakty relé
Network interface (Mbps)	10/100/1000
Physical parameters
Depth (mm)	115
Design	DIN rail
Efficiency (%)	91
Height (mm)	130
Operating Temperature	-40° až +60°C
Weight (kg)	0.3
Width (mm)	46
Powering
PoE	No
