IMCO POWER TIC241.H 24_1210, converter 24V DC/12V DC, 120W

Name: IMCO POWER TIC241.H 24_1210, converter 24V DC/12V DC, 120W
Brand: IMCO POWER
SKU: 50140
Price: 270.96 EUR
Availability: OutOfStock

Industrial DC/DC converter 18-35V/12V (10A) with galvanic department, with remote signal Soft Start and Prevention on DIN rail.More information

Producer

IMCO POWER

Part No.

EV004261

Code

00070522

Warranty

36 Month

Availability

Availability in stores

Order

Your price exc. VAT

223.94 EUR exc. VAT

VAT

21%

Your price inc. VAT

270.96 EUR inc. VAT

Ask for a better price

Description

DC voltage converter TIC241.H 24_1210 converts the input voltage 18-35 V to the output voltage of 12 v with galvanic separation. The converter is equipped with a local LED indication on the front panel, the long-distance signaling is via a free relay contact.

The converter is designed to mount on din bar . Connecting input, output and signaling is via the removable connector at the bottom of the converter with a cross-section of wires up to 2.5 mm2.

Parameters

Ethernet parameters
DC Output Voltage (V)	12
DIN rail mounting	Yes
Input Voltage (V)	24
Local signalling	LED
Ochrana proti přepětí	Ne
Output Current (A)	10
Output Power (W)	120
Properties	Tepelná ochrana, Ochrana proti zkratu, Ochrana proti podpětí
Rack mounting	Ne
Remote signalling	Kontakty relé
Network interface (Mbps)	10/100/1000
Physical parameters
Depth (mm)	115
Design	DIN rail
Efficiency (%)	93
Height (mm)	130
Operating Temperature	-40° až +60°C
Weight (kg)	0.3
Width (mm)	46
Powering
PoE	No
