      EnGenius EWS7952P-FIT (FitSwitch 48 PoE)
      Compare Set Watchdog

      EnGenius EWS7952P-FIT (FitSwitch 48 PoE)

      Engenius EWS7952P-Fit is POE Switch from the Engenius FIT series. It is equipped with 48x POE RJ45 ports and 4x SFP ports with configuration. It supplies compatible POE devices according to 802.3af/802.3AT, such as IP cameras, VoIP phones and AP. Total Poe Budget is 410 W.More information

      Producer
        EnGenius

      Part No.


      EWS7952P-FIT


      Code
       00072648
      Warranty
      24 Month
      Availability

      in stock
      Availability in stores
      Order

      Add to cart
      Your price exc. VAT
      652.38 EUR exc. VAT
      VAT
      21%
      Your price inc. VAT
      789.38 EUR  inc. VAT

      Ask for a better price

        Ask for a better price

        Your e-mail
        Phone
        Quantity
        Comment

        Description

        Engenius Fit is a series of access points and switches so that it fits perfectly with both homes and small companies and offices looking for top quality at available price . This robust and safe solution comes with Wi-Fi at a business level at affordable and high quality hardware that can be set in minutes. Access points and switches can be operated immediately in several modes to meet all types of operations:
        • Separate access points and switches without central management
        • central cloud management FITEXPRESS (Mobile Application/Web)
        • Local controller FitController


        Engenius EWS7952P-Fit is 48 -Port poe switch from the Engenius fit series. It is equipped with 48x PoE RJ45 ports and 4x SFP ports with the possibility of local or central configuration, monitoring and management of network and easy-to-use web interface. It powers compatible poe devices according to standards 802.3af/802.3at , such as IP cameras, VoIP phones and AP. The total Power Budget is 410 W .
        name value
        MAC Address Table: 8K
        jumbo frame: 9000 B
        Multicast Group: max 256 groups
        BLD SNOOPING: BLD SNOOPING: V1
        QOS: 8 front
        Strict
        WRR
        Strict + Wrr
        QoS modes: cos /802.1p
        DSCP
        Cos/802.1P-DSCP
        Access Control List (ACL): MAC BASED ACL
        IPv4 /IPv6 Based ACL
        ACL Binding
        • Central management using Engenius Fitxpress/FitController or Local Administration
        • 48x Gigabit Ethernet Port + 4x SFP Port
        • Full-Featured Layer 2 Switching
        • jumbo frame 9000b
        • Support Qos, RSTP/MSTP, LLDP, IGMP Snooping
        • Full support for VLAN, support Voice VLAN
        • automatic creation of network topology with other Engenius products
        • POE 802.3AF/AT All ports with a total budget of POE 410 W
        • Desktop version

          switching capacity
        • 104 Gbps

          PoE power
        • ports 1-48 (802.3af/at)
        • Power input 410 W

          l3 function
        • Multiple IP Interface (20 IPv6 addresses)
        • Arp Table (192 records)
        • IPv4 static Route (63 records)
        • IPv6 Static Route (21 records)

        Additional features

        • 802.1D SPANNING Tree, Loopback Detection, Multicast Filitering, IGMP Multicast Forwarding, IGMP SNOOPING, BLD Multicast Forwarding, 802.1Q VLAN Tagging, 802.3x Flow Control, 802.3AD Link Aggregation, IPv4 DHCP Relay, IPv4 DHCP Snooping, IPv4 DHCP Snooping Source Mac Address Check-up, ARP Inspection, Arp Packet Validation Settings, IEEE 802. 3AZ Energy Efficient Ethernet (EEE), Command Line Interface (CLI), SSH Server, Telnet Server, TFTP Client, Configuration Upgrade/Backup, Simple Network Time Protocol (SNTP), Syslog, 802.1D Spanning Tree.

        Package content:

        • 1x EWS7952P-Fit
        • 1x power cord, EU ending
        • 1x Kit for Mounting to Rack
        • 1x fast user manual

        Parameters

        Input Voltage (V) 230
        IPv6 support Yes
        Management Yes
        Power Supply AC

        Ethernet parameters
        Network interface (Mbps) 10/100/1000
        Number od RJ45 ports 48
        Number of SFP (1G) ports 4
        Number of SFP+ (10G) ports 0

        Physical parameters
        Depth (mm) 310
        Design Rackmount, Standalone
        Height (mm) 44
        Height (U) 1
        Operating Temperature 0° až +50 °C
        Weight (kg) 3.9
        Width (mm) 440

        PoE parameters
        Number of PoE ports 48
        PoE budget (W) 410
        PoE standard 802.3at, 802.3af

        Powering
        PoE Yes
        Typ zdroje PoE
